Cylindrical Cell Pneumatic Sealer for Battery Sealing
Model Number:
Tmax-crimper004Dimension(L*W*H):
W1200mm*D690mm*H1765mmNet Weight:
800lbsCompliance:
CE CertifiedWarranty:
Two Year Limited Warranty With Lifetime SupportPayment:
T/T, Credit Card, Paypal, LC, Western UnionDelivery Time:
3 Days
Wechat:13506084915
Cylindrical Cell Pneumatic Sealer for Battery Sealing
It is anauto crimper designed for sealing the cylindrical battery cases. It provides a continues workflow for casebatchloading - crimping - case unloading without dedicated labor.
Advanced Features:
Efficient batchloading/unloadingmechanism with case feeding conveyor
·Dedicated Four-step crimping process (1st & 2nd trials for pre-deformation, 3rd trial for complete sealing and 4th trial for case consolidation) ensures the most stable & consistent sealing quality
·Crimping speed and pressure is adjustable
·User-friendly human-machine interface with PLC touch screen control
·Floor-Stand enclosure with transparent front & side openable windows allow clear process monitoringand adjustment
Specifications:
|
Working Voltage |
110/220V AC, 50/60Hz, three Phase |
|
Max. Power Consumption |
4KW |
|
Driving Force |
Penumatic, 0.5 - 0.8 MPa compression gas is required |
|
Compatibility
|
Standard crimping capability for 18650 case |
|
Control
|
User-friendly HMI with PLC touch screen control ensures easy program setup
|
|
Crimping Force
|
Upto6kgf/cm²
|
|
Productivity
|
·30 pieces per minute ·Material feeding conveyor is able to loadupto22 pcs per batch |
|
Warranty
|
·One year limited with lifetime support ·Parts rusted without regular cleaning and maintenance are not covered |
|
Product Dimensions
|
W1200mm*D690mm*H1765mm |
|
Net Weight
|
800 lbs |
