Customized Size and PPI Nickel Foam Metal Foam
Model Number:
TMAX-Nickel-Foam6Dimension(L*W*H):
0.2-10 mm ThicknessCompliance:
CE certificatePayment:
T/T, Credit Card, Paypal, LC, Western UnionDelivery Time:
3 Days
Wechat:13506084915
Customized Size and PPI Nickel Foam Metal Foam
Applicable to super capacitor, nickel hydrogen battery, nickel cadmium battery, fuel cell........
SPECIFICATION:
|
Item |
value |
|
Thicness |
1.5mm 1.0mm 0.5mm 1.7mm It can be customized |
|
Porosity |
97% |
|
Purity |
≥99.8% |
|
PPI |
5-130 It can be customized |
|
Areal density |
350±20g/m2 |
|
Used for super capacitor, nickel hydrogen battery, nickel cadmium battery, fuel cell........ |
|
Dimension (Thickness* Length*Width)
|
8mm*300mm*200mm |
7mm*300mm*500mm |
6mm*300mm*200mm |
|
5mm*300mm*200mm |
4mm*300mm*200mm |
3mm*300mm*200mm |
|
2mm*300mm*200mm |
1.7mm*300mm*200mm |
1.6mm*300mm*200mm |
|
1.5mm*300mm*200mm |
1.0mm*300mm*200mm |
0.5mm*300mm*200mm |
|
0.3mm*300mm*200mm |
0.2mm 200mm*300mm |
The size can be customized |
